| Part Number: | APC0401-37718 |
|---|---|
| Length: | 4.00mm |
| Working Stroke: | 0.40mm |
| Full Stroke: | 0.50mm |
| Plunger OD: | φ0.70mm |
| Barrel OD: | φ1.30mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 1.0A |
| Spring Force: | 70gf |
| Coating: | Au 2u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-18111 |
|---|---|
| Length: | 6.25mm |
| Working Stroke: | 0.80mm |
| Full Stroke: | 1.00mm |
| Plunger OD: | φ0.70mm |
| Barrel OD: | φ1.20mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 4.0A |
| Spring Force: | 60~80gf |
| Coating: | Au 0.75um |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-23627 |
|---|---|
| Length: | 6.35mm |
| Working Stroke: | 0.80mm |
| Full Stroke: | 1.40mm |
| Plunger OD: | φ0.90mm |
| Barrel OD: | φ1.50mm |
| Contact Resistance: | 100mΩ |
| Voltage: | 12V |
| Current: | 1.0A |
| Spring Force: | 80gf |
| Coating: | Au 5u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-21352 |
|---|---|
| Length: | 7.40mm |
| Working Stroke: | 1.00mm |
| Full Stroke: | 1.20mm |
| Plunger OD: | φ1.00mm |
| Barrel OD: | φ1.50mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 42V |
| Current: | 1.0A |
| Spring Force: | 50gf |
| Coating: | Au 20u” |
| Temperature: | -40℃~+85℃ |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-6961 |
|---|---|
| Length: | 7.75mm |
| Working Stroke: | 1.10mm |
| Full Stroke: | 1.30mm |
| Plunger OD: | φ0.90mm |
| Barrel OD: | φ1.40mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 4.2V |
| Current: | 4.0A |
| Spring Force: | 62.5gf |
| Coating: | Au 10u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-16578 |
|---|---|
| Length: | 7.90mm |
| Working Stroke: | 1.00mm |
| Full Stroke: | 1.40mm |
| Plunger OD: | φ0.90mm |
| Barrel OD: | φ1.40mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 4.2V |
| Current: | 5.0A |
| Spring Force: | 60gf |
| Coating: | Au 10u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 12 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-33245 |
|---|---|
| Length: | 8.30mm |
| Working Stroke: | 1.00mm |
| Full Stroke: | 1.40mm |
| Plunger OD: | φ0.90mm |
| Barrel OD: | φ1.50mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 2.0A |
| Spring Force: | 100gf |
| Coating: | Au 5u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-23522 |
|---|---|
| Length: | 9.10mm |
| Working Stroke: | 1.20mm |
| Plunger OD: | φ1.50mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 2.0A |
| Spring Force: | 100gf |
| Coating: | Au 5u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 20,000 cycles |
| Part Number: | APC0401-24866 |
|---|---|
| Length: | 9.25mm |
| Working Stroke: | 2.30mm |
| Plunger OD: | φ1.00mm |
| Barrel OD: | φ1.60mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 3.0A |
| Spring Force: | 100gf |
| Coating: | Au 10u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 20,000 cycles |
| Part Number: | APC0401-32860 |
|---|---|
| Length: | 9.90mm |
| Working Stroke: | 1.30mm |
| Full Stroke: | 2.00mm |
| Plunger OD: | φ1.00mm |
| Barrel OD: | φ1.50mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 5.0A |
| Spring Force: | 110gf |
| Coating: | Au 10u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-10483 |
|---|---|
| Length: | 10.10mm |
| Working Stroke: | 1.21mm |
| Plunger OD: | φ1.00mm |
| Barrel OD: | φ1.47mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 1.0A |
| Spring Force: | 100gf |
| Coating: | Au 4u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-21121 |
|---|---|
| Length: | 10.10mm |
| Working Stroke: | 0.90mm |
| Full Stroke: | 1.15mm |
| Plunger OD: | φ0.90mm |
| Barrel OD: | φ1.50mm |
| Contact Resistance: | 15mΩ |
| Voltage: | 4.2V |
| Current: | 8.0A |
| Spring Force: | 130gf |
| Coating: | Au 10u” |
| Temperature: | -40℃~+85℃ |
| Durability | 10,000 cycles |
| Part Number: | APC0401-22367 |
|---|---|
| Length: | 10.30mm |
| Working Stroke: | 1.00mm |
| Plunger OD: | φ1.40mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 12V |
| Current: | 5.0A |
| Spring Force: | 140gf |
| Coating: | Au 10u” |
| Temperature: | -25℃~+85℃ |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-18363 |
|---|---|
| Length: | 10.31mm |
| Working Stroke: | 1.15mm |
| Full Stroke: | 2.30mm |
| Plunger OD: | φ1.07mm |
| Barrel OD: | φ1.50mm |
| Contact Resistance: | 20mΩ |
| Voltage: | 12V |
| Current: | 2.0A |
| Spring Force: | 60gf |
| Coating: | Au 20u” |
| Temperature: | -40℃~+85℃ |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-16095 |
|---|---|
| Length: | 10.50mm |
| Working Stroke: | 0.70mm |
| Plunger OD: | φ0.65mm |
| Barrel OD: | φ1.20mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 10V |
| Current: | 1.5A |
| Spring Force: | 65gf |
| Coating: | Au 32u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 25,000 cycles |
| Part Number: | APC0401-31915 |
|---|---|
| Length: | 10.80mm |
| Working Stroke: | 1.50mm |
| Full Stroke: | 2.20mm |
| Plunger OD: | φ1.50mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 12V |
| Current: | 5.0A |
| Spring Force: | 200gf |
| Coating: | Au 15u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-28380 |
|---|---|
| Length: | 10.90mm |
| Working Stroke: | 1.60mm |
| Plunger OD: | φ1.50mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 3.0A |
| Spring Force: | 120gf |
| Coating: | Au 10u” |
| Temperature: | -25℃~+85℃ |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-24215 |
|---|---|
| Length: | 13.00mm |
| Working Stroke: | 1.30mm |
| Plunger OD: | φ1.00mm |
| Barrel OD: | φ1.60mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 12V |
| Current: | 3.0A |
| Spring Force: | 120gf |
| Coating: | Au 10u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 20,000 cycles |
| Part Number: | APC0401-28534 |
|---|---|
| Length: | 13.30mm |
| Working Stroke: | 1.00mm |
| Full Stroke: | 2.20mm |
| Plunger OD: | φ1.50mm |
| Barrel OD: | φ2.20mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 2.0A |
| Spring Force: | 120gf |
| Coating: | Au 5u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-28793 |
|---|---|
| Length: | 13.30mm |
| Working Stroke: | 1.00mm |
| Full Stroke: | 2.20mm |
| Plunger OD: | φ1.40mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 12V |
| Current: | 5.0A |
| Spring Force: | 200gf |
| Coating: | Au 10u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-40195 |
|---|---|
| Length: | 13.70mm |
| Working Stroke: | 1.10mm |
| Plunger OD: | φ1.40mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 20mΩ |
| Voltage: | 18V |
| Current: | 17.0A |
| Spring Force: | 95gf |
| Coating: | Au 32u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 25,000 cycles |
| Part Number: | APC0401-40187 |
|---|---|
| Length: | 13.77mm |
| Working Stroke: | 1.10mm |
| Plunger OD: | φ1.38mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 20mΩ |
| Voltage: | 18V |
| Current: | 17.0A |
| Spring Force: | 95gf |
| Coating: | Au 32u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 25,000 cycles |
| Part Number: | APC0401-32027 |
|---|---|
| Length: | 14.00mm |
| Working Stroke: | 1.30mm |
| Full Stroke: | 2.20mm |
| Plunger OD: | φ2.50mm |
| Barrel OD: | φ3.50mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 12V |
| Current: | 3.0A |
| Spring Force: | 120gf |
| Coating: | Pd 5u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 30,000 cycles |
| Part Number: | APC0401-27981 |
|---|---|
| Length: | 15.00mm |
| Working Stroke: | 1.30mm |
| Full Stroke: | 2.20mm |
| Plunger OD: | φ4.00mm |
| Barrel OD: | φ5.00mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 12V |
| Current: | 3.0A |
| Spring Force: | 160gf |
| Coating: | Pd 5u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 30,000 cycles |
| Part Number: | APC0401-21898 |
|---|---|
| Length: | 16.00mm |
| Working Stroke: | 2.00mm |
| Full Stroke: | 2.80mm |
| Plunger OD: | φ1.50mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 12V |
| Current: | 3.0A |
| Spring Force: | 160gf |
| Coating: | Au 20u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 30,000 cycles |
| Part Number: | APC0401-21905 |
|---|---|
| Length: | 16.00mm |
| Working Stroke: | 2.00mm |
| Full Stroke: | 2.80mm |
| Plunger OD: | φ2.50mm |
| Barrel OD: | φ3.00mm |
| Contact Resistance: | 30mΩ |
| Voltage: | 12V |
| Current: | 3.0A |
| Spring Force: | 160gf |
| Coating: | Au 20u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 30,000 cycles |
| Part Number: | APC0401-29143 |
|---|---|
| Length: | 17.50mm |
| Working Stroke: | 1.00mm |
| Plunger OD: | φ1.40mm |
| Barrel OD: | φ2.00mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 2.0A |
| Spring Force: | 100gf |
| Coating: | Au 10u” |
| Temperature: | -25℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
| Part Number: | APC0401-40099 |
|---|---|
| Length: | 19.30mm |
| Working Stroke: | 1.78mm |
| Full Stroke: | 2.00mm |
| Plunger OD: | φ1.52mm |
| Barrel OD: | φ2.39mm |
| Contact Resistance: | 50mΩ |
| Voltage: | 12V |
| Current: | 1.0A |
| Spring Force: | 145gf |
| Coating: | Au 32u” |
| Temperature: | -40℃~+85℃ |
| Salt Spray: | 48 hours |
| Durability: | 10,000 cycles |
