4 Pin Connector Description:
Product Info: Johoty’s 4 Pin Connector offers top-notch performance for high-end applications. It’s compact and built with advanced techniques to ensure reliable connections. Each connector is rigorously tested for performance under heavy loads and tough conditions.
Product Features: This 4 Pin Connector is highly stable and resistant to interference. Its small pitch design allows for high-density connections in tight spaces, and the magnetic feature makes plugging in and unplugging easy and reliable. It’s also waterproof for stable use in wet environments.
Problem Solving: For clients needing stable connections in compact spaces, this 4 Pin Connector addresses issues like poor contact and interference. Its waterproof and magnetic features make it perfect for tough conditions, cutting down on both upkeep and expenses.
Specifications: The high-precision 4 Pin Connector has a pitch as small as 1mm, perfect for tight spaces. It’s carefully crafted to fit different devices, and we can create custom sizes to match your exact needs.
Applications: It’s used in automotive electronics, marine industry, industrial automation, military tech, medical devices, radio equipment, and consumer electronics. Whether it’s for durable automotive control systems or waterproof medical devices, this 4 pin connector offers reliable support.
Target Industries: Our main customers include car manufacturers, R&D engineers, industrial equipment makers, medical device suppliers, and consumer electronics companies. For these industries, precision and stability are crucial for reliable equipment.
Customer Benefits: With Johoty’s 4 Pin Connector, customers get exceptional stability, durability, and ease of use, ensuring reliable performance for their applications.
Catalogs of 4 Pin Connector:
4 Pin Connector Datasheet:
| Category | Precision Range | Features | Function | Benefits | Applications |
|---|---|---|---|---|---|
| Pitch | 0.5mm – 2.0mm | Small pitch | Reduces space between pins | Saves space, compact design | Mobile devices, compact electronics |
| Pin Count | 4 Pins | Fixed pin count | Ensures stable connections | Reliable connection, consistent performance | Automotive, consumer electronics |
| Current Rating | 0.5A – 10A | High current handling | Transmits electrical current safely | Enhanced power delivery | Power supplies, LED lighting |
| Voltage Rating | 1V – 500V | High voltage tolerance | Prevents electrical arcing | Safe operation under high voltage | Industrial machinery, power equipment |
| Insulation Resistance | >1000MΩ | High insulation resistance | Prevents electrical leakage | Improved safety, reduced risk of short circuits | High-voltage applications |
| Contact Resistance | >15mΩ | Low contact resistance | Ensures minimal signal loss | Better signal integrity, reliable performance | Communication devices, sensors |
| Temperature Range | -40°C to 125°C | Wide temperature tolerance | Operates across a broad temperature range | Versatile use in various environments | Automotive, aerospace |
| Waterproof Rating | IP65 – IP69K | Waterproof and dustproof | Protects against water and dust ingress | Increased durability, reliability | Outdoor electronics, marine applications |
| Magnetic Function | Yes/No | Magnetic coupling option | Provides easy alignment and connection | Simplified connection process | Robotics, modular systems |
| Mounting Type | Surface mount, Through-hole | Various mounting options | Flexible installation | Adaptable to different design requirements | PCB assembly, enclosures |
| Material | Plastic, Metal, Composite | Durable construction | Enhances physical robustness | Increased lifespan and durability | High-stress environments |
| Locking Mechanism | Latch, Screw, Push-pull | Secure locking | Prevents accidental disconnection | Improved connection stability | Industrial connectors, power systems |
| Shielding | Yes/No | Shielded or unshielded options | Reduces electromagnetic interference | Enhanced signal quality, noise reduction | High-frequency applications |
| Connector Type | Male, Female | Gender-specific connectors | Ensures proper mating and connection | Avoids mismatched connections | General-purpose electronics |
| Cable Flexibility | Flexible, Rigid | Cable flexibility | Accommodates varying installation conditions | Easier to route and install | Consumer electronics, cable assemblies |
| Size | Miniature, Standard | Various sizes | Suitable for different form factors | Customizable to application needs | Portable devices, compact spaces |
| Contact Plating | Gold, Tin, Nickel | Different plating options | Enhances corrosion resistance and conductivity | Better performance and longevity | High-frequency connectors |
| Mechanical Durability | >10,000 cycles | High cycle durability | Ensures long-term reliability | Reduces maintenance and replacement frequency | Industrial use, frequent connect/disconnect |
| Electrical Durability | >10,000 cycles | High electrical durability | Maintains performance over numerous cycles | Consistent electrical performance | Power connectors, signal connectors |
| Insertion Force | Low, Medium, High | Varying insertion forces | Ensures ease of insertion and retention | Customizable to user preference | Consumer devices, industrial connectors |
| Extraction Force | Low, Medium, High | Varying extraction forces | Provides secure connections | Reduces risk of accidental disconnection | Safety-critical applications |
Why Choose Johoty’s 4 Pin Connector As Priority?
Choose our 4 Pin Connector for its tiny pitch, top-notch stability, and superior waterproofing. 1000 hours in salt spray, Features magnetic snap-on for quick, reliable connections. With 98% customer satisfaction, it guarantees efficient and dependable connectivity. Order now!
4 Pin Connector Benefits:
Stable Quality: Ensuring Reliable Connections
Our high-precision 4 Pin Connector is designed to offer exceptional connection stability. We closely monitor every part of the design and production process to make sure everything meets our high standards.
Specifically, our connectors endure over 10,000 plug-in cycles and have a leading contact resistance of just 15mΩ. This high stability helps prevent poor connections and signal interference, ensuring reliability even under high-frequency, high-load conditions.
Each 4 Pin Connector undergoes rigorous quality checks and certification, providing solid assurance for our customers.
High Cost-Effectiveness: Optimizing Your Investment
Our high-precision 4 Pin Connector offers excellent value for money. By optimizing production processes and material choices, we reduce production costs while maintaining quality, making our connectors highly competitive in the market.
For example, compared to traditional products, our 4 Pin Connector is priced 15% lower for the same performance and offer a longer lifespan, reducing overall procurement and maintenance costs.
We also offer flexible bulk purchasing options, allowing us to adjust production based on customer needs, further enhancing cost-effectiveness.
Fast Delivery: Shortening Lead Times and Boosting Response
To meet urgent customer needs, our high-precision 4 Pin Connector boasts industry-leading delivery speeds. We use efficient logistics and production management systems to cut standard order lead times to 7-10 days, which is 20% faster than the industry average.
For rush orders or special requests, we offer expedited services to ensure you get your connectors as quickly as possible. Additionally, our real-time order tracking system lets customers check their order status anytime, enhancing service transparency and convenience.
Custom Services: Tailored to Meet Unique Needs
We know every customer has unique requirements, so we offer comprehensive custom services. You can customize the specifications, materials, and features of our 4 Pin Connector based on your specific application and technical needs.
For instance, we can adjust pin configurations, conductor materials, and housing protection levels to match your exact requirements. Our CFT crew partners with you to guarantee that every detail, from design through production, is exactly what you’re looking for.
This tailored approach not only enhances the compatibility of our connectors but also gives you a competitive edge in the market.
4 Pin Connector Applications:
Medical Equipment
- Background: In modern medical devices, reliable connectors are crucial for precise operation and data transmission. This is especially true for remote monitoring devices, where stable signal transmission directly impacts the accuracy of patient health monitoring.
- Challenge: Medical environments often involve moisture and cleaning. Traditional connectors can suffer performance degradation under these conditions. There’s a need to address waterproofing issues in small-pitch designs while maintaining stability over long-term use.
- Solution: We introduced a high-precision 4 Pin Connector with an IP68 rating and a small-pitch design to ensure stable connections even in humid environments. Made from high-strength materials and utilizing precision manufacturing techniques, this connector offers enhanced waterproofing and durability.
- Implementation: After integrating the 4 Pin Connector into medical devices, we conducted 5,000 insertion and removal tests to ensure performance stability and leak-proof operation under frequent use and cleaning conditions. The tests showed that the 4 Pin Connector performs exceptionally well in high-humidity environments.
- Results: Failure rates of devices dropped by 30%, signal stability improved by 25%, maintenance frequency decreased, operational costs were significantly reduced, and user satisfaction greatly increased.
Automated Production Line
- Background: In automated production lines, connectors must withstand high temperatures, vibrations, and dust to ensure continuous and stable equipment operation.
- Challenge: The complex environment of production lines requires connectors that not only resist high temperatures but also have dust and water resistance to handle dust and liquid intrusion.
- Solution: Our small-pitch high-precision 4 Pin Connector, with an IP67 rating and high-temperature tolerance, performs reliably in extreme conditions. The design includes advanced sealing technology to prevent dust and liquid intrusion.
- Implementation: In the production line, the 4 Pin Connector was deployed and tested under challenging conditions, including high temperatures and vibrations, to ensure its durability and performance.
- Results: Production efficiency improved by 20%, and equipment breakdowns dropped by 35%. Maintenance costs went down, overall line efficiency increased noticeably, and customer feedback was positive
Communication Equipment
- Background: In communication devices, connectors must handle high-frequency signal transmission and maintain stable performance over time. The reliability of these connections directly impacts data transfer quality.
- Challenge: High-frequency signal transmission demands exceptional electrical performance and stability from connectors, as well as addressing contact stability in compact sizes.
- Solution: Our small-pitch high-precision 4 Pin Connector uses highly conductive materials and precise manufacturing techniques to ensure stable high-frequency signal transmission. Each connector undergoes strict electrical performance testing to prevent signal degradation.
- Implementation: In communication devices, the 4 Pin Connector was tested with over 50,000 insertions and removals, ensuring stable signal transmission and consistent performance.
- Results: Data transfer rates increased by 15%, and signal stability improved by 20%. Customers reported fewer device failures and significantly enhanced overall system performance.
Consumer Electronics
- Background: Consumer electronics demand connectors that are compact and aesthetically pleasing while ensuring reliability for frequent use and unplugging.
- Challenge: In compact designs, connectors must offer high stability and protection to withstand everyday wear and environmental changes.
- Solution: Our small-pitch, high-precision 4 Pin Connector is designed for both aesthetics and durability, featuring excellent waterproof and dustproof properties. Precision engineering ensures reliable performance in tight spaces.
- Execution: The 4 Pin Connector was used in consumer electronics and underwent 3000 insertion tests. It performed consistently without performance degradation under high-frequency use and various environmental conditions.
- Result: Product reliability improved, and user complaints decreased by 20%. Positive market feedback and increased customer trust and satisfaction were achieved.
Automotive Electronics
- Background: Automotive electronics require connectors that perform reliably under vibration, temperature fluctuations, and moisture to ensure vehicle functions operate smoothly.
- Challenge: High vibration and extreme temperatures in automotive environments demand connectors with high durability and protection to prevent failures due to environmental changes.
- Solution: Our small-pitch, high-precision 4 Pin Connector offers excellent vibration resistance, high-temperature tolerance, and an IP65 protection rating, suitable for harsh automotive environments.
- Execution: The 4 Pin Connector was tested over 30,000 kilometers in automotive electronics. It maintained stable performance without contact failures under high vibration and temperature changes.
- Result: Failure rates in automotive electronic systems decreased by 25%, with system stability improving by 30%. The ride got much smoother, upkeep costs went down, and customers were happier.
Aerospace
- Background: Aerospace applications demand connectors with high reliability, especially under extreme temperatures and high radiation, maintaining stable electrical performance and mechanical strength.
- Challenge: Extreme temperature changes and radiation in aerospace environments impose strict requirements on connectors to ensure reliability.
- Solution: Our small-pitch, high-precision 4 Pin Connector excels in high-temperature resistance and radiation protection, meeting the stringent standards of aerospace applications.
- Execution: The 4 Pin Connector was tested in aerospace equipment under extreme temperatures and radiation. It remained stable with no performance degradation.
- Result: Equipment reliability increased, with failure rates dropping by 30%. Mission success rates improved significantly, and overall device reliability was greatly enhanced.
Industrial Equipment
- Background: Industrial equipment operates in complex environments that demand high durability and stability from connectors. They must maintain reliable connections under conditions like dust and oil.
- Challenge: Industrial settings involve dust and oil, requiring connectors with high protection and stable electrical connections.
- Solution: Our small-pitch, high-precision 4 Pin Connector offers IP67 protection, effectively preventing dust and oil ingress while ensuring stable connections.
- Execution: The 4 Pin Connector was used in industrial equipment and tested for over 8000 hours. It performed reliably in harsh conditions with no failures.
- Result: Equipment failure rates decreased by 30%, maintenance costs were significantly reduced, and overall equipment efficiency improved. Customer satisfaction increased.
Power Tools
- Background: Power tools require connectors with high durability to withstand frequent plugging and unplugging while ensuring reliable connections.
- Challenge: Frequent use of power tools involves high-frequency operations, so connectors must remain stable and durable despite frequent handling and wear.
- Solution: Our small-pitch, high-precision 4 Pin Connector is designed for high wear resistance and protection, ideal for applications with frequent plugging and unplugging.
- Execution: The 4 Pin Connector was tested in power tools with 5000 insertion cycles. It performed consistently under high-frequency use, showing no significant performance degradation.
- Result: The lifespan of power tools was extended, failure rates decreased by 20%, and customer feedback highlighted stable performance. Market competitiveness improved, leading to increased product sales.
4 Pin Connector Advantages:
Tiny Pitch Design: Maximizing Space Efficiency
- Our Connectors feature an ultra-small 0.5mm pitch design, making it perfect for tight spaces where every millimeter counts. This design not only saves valuable space but also allows engineers to pack more functionality into smaller areas, enhancing the overall look of the product.
- After 10,000 insertion and removal cycles, the 4 Pin Connector maintains a contact resistance of just 15mΩ—much lower than traditional connectors. This extremely tight pitch not only increases contact density but also boosts the device’s ability to resist interference, ensuring stable high-frequency signal transmission.
- For high-density applications like medical devices and advanced consumer electronics, the 0.5mm pitch is a game-changer.
High Stability Performance: Ensuring Long-Term Reliability
- Our Connectors excel in stability, maintaining a contact resistance of just 15mΩ after 10,000 cycles—well below industry standards.
- We use high-conductivity alloy materials and multiple gold-plated contact points to achieve this low resistance. This design prevents signal loss due to poor contact, ensuring the 4 Pin Connector remains stable over long periods.
- For applications requiring high reliability, like automated production lines and communication systems, this 4 Pin Connector significantly reduces failure rates and improves overall system efficiency and reliability.
Superior Waterproof and Dustproof Features: Ready for Harsh Environments
- Our Connectors are IP68-rated for both waterproof and dustproof capabilities. It can stay underwater at 5 feet deep for 48 hours without any leaks.
- Additionally, it effectively blocks dust particles larger than 1mm, ensuring reliable performance even in extreme conditions. The specially treated sealing rings and precise pin design guarantee consistent operation in high humidity and dusty environments.
- This rugged protection makes the 4 Pin Connector ideal for outdoor equipment, automotive electronics, and industrial control systems, safeguarding connection quality from environmental impacts and ensuring long-term stable operation.
Magnetic Connection Mechanism: Boosting Ease of Use
- Our innovative magnetic connection mechanism offers users incredible convenience. This feature allows the 4 Pin Connector to align and connect in just 0.2 seconds, drastically cutting down setup time and minimizing alignment errors that can occur with manual connections.
- The magnetic design ensures precise alignment every time and maintains a secure connection even in vibrating or jolting environments. This boosts how quickly things get done while cutting down on equipment wear and tear from bad connections.
- It’s perfect for applications that require quick changes or high flexibility, enhancing overall production line reliability and adaptability.
Excellent Temperature Adaptability: Reliable Performance in Extreme Conditions
- Our Connectors perform exceptionally well across a wide temperature range from -50°C to +125°C. After going through numerous thermal cycles, it keeps its electrical performance consistent, even in the harshest temperature conditions.
- This temperature stability comes from using special high-temperature alloys and top-quality insulation materials, which resist the effects of thermal expansion and contraction.
- For equipment operating in harsh environments, like aerospace and deep-sea exploration, this temperature adaptability ensures that Connectors remain reliable and perform consistently in all extreme conditions.
Customization Services: Tailored to Your Needs
- Johoty provides tailored customization options to perfectly match your unique needs. We can adjust the 4 Pin Connector length, pin configuration, or protection level based on your needs.
- Additionally, we offer expedited services to meet urgent requests, speeding up the product delivery time. This flexible customization not only caters to your exact application needs but also accelerates your time-to-market, boosting your competitive edge.
- With our customization options, you get Connectors that perfectly fit your requirements, optimizing your product design and increasing market share and customer satisfaction.
FAQ
Primarily designed for power and signal transmission. The 4-pin connector finds extensive applications in consumer electronics, LED lighting, automotive electronics, industrial automation, and more.
Selecting the right 4 pin connector requires consideration of the application’s electrical requirements, e.g. voltage, and current. environmental conditions, e.g. temperature, humidity, whether water and dustproofing are required? Mechanical characteristics, e.g. number of plugs and unplugs, locking mechanism. and dimensional constraints.
Electrical ratings include the maximum withstand voltage and current. Which determines the electrical range in which the connector can be safely used.
Yes, some connectors are designed to support data transfer for applications that require both power and data transfer.
Some connectors are designed to be waterproof. It varies based on the particular design, often featuring popular waterproof ratings like IP67 or IP68.
The mounting method depends on the type and design of the connector, can be fixed by screws, snap locking, or soldering.
Reliability testing includes electrical testing, e.g. insulation resistance, and contact resistance testing. Mechanical testing, e.g. insertion and extraction force testing, vibration and shock testing. Environmental testing, e.g. temperature and humidity cycling, salt spray testing.
Yes, we offer customization services, including customizing pin configurations, dimensions, materials, and special performance. Our goals are to adequately address the needs of various distinct applications.
This depends on its design, materials, and conditions of use. High-quality 4 pin connector can last for up to 500 thousand cycles.
The price depends on the type of 4 pin connector, material, performance requirements, and quantity purchased. The pricing spectrum can extend starting at only a few cents and going up to tens of dollars.
