Catalogs of Threaded Screw Pogo Pins, Length 6.00~70.00mm:

Part Number:	APC0401-26000
Length:	6.00mm
Working Stroke:	1.00mm
Full Stroke:	1.50mm
Plunger OD:	φ1.20mm
Barrel OD:	M2.50
Contact Resistance:	50mΩ
Voltage:	12V
Current:	2.0A
Spring Force:	100gf
Coating:	Au 40u”
Temperature:	-25℃~+85℃
Salt Spray:	48 hours
Durability:	30,000 cycles

Part Number:	APC0401-13624
Length:	9.50mm
Working Stroke:	1.00mm
Full Stroke:	1.20mm
Plunger OD:	φ0.80mm
Barrel OD:	φ1.30mm
Tail Pin:	M1.6*0.35,L:3.00mm
Contact Resistance:	50mΩ
Voltage:	12V
Current:	1.0A
Spring Force:	70gf
Coating:	Au 4u”
Temperature:	-30℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-13631
Length:	10.50mm
Working Stroke:	1.00mm
Full Stroke:	1.20mm
Plunger OD:	φ0.80mm
Barrel OD:	φ1.30mm
Tail Pin:	M1.6*0.35,L:3.00mm
Contact Resistance:	50mΩ
Voltage:	12V
Current:	1.0A
Spring Force:	70gf
Coating:	Au 4u”
Temperature:	-30℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-11563
Length:	10.90mm
Working Stroke:	2.50mm
Full Stroke:	3.00mm
Plunger OD:	φ0.60mm
Barrel OD:	φ1.95mm
Tail Pin:	M3*0.5
Contact Resistance:	50mΩ
Voltage:	230V
Current:	1.0A
Spring Force:	100gf
Coating:	Au 10u”
Temperature:	-40℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-22101
Length:	14.00mm
Working Stroke:	2.50mm
Full Stroke:	3.00mm
Plunger OD:	φ1.40mm
Barrel OD:	φ1.95mm
Tail Pin:	M3*0.5
Contact Resistance:	50mΩ
Voltage:	230V
Current:	1.0A
Spring Force:	100gf
Coating:	Au 10u”
Temperature:	-40℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-49905
Length:	15.60mm
Working Stroke:	2.00mm
Full Stroke:	3.60mm
Plunger OD:	φ2.90mm
Barrel OD:	φ3.50mm
Tail Pin:	φ5.1*0.6
Contact Resistance:	＜100mΩ
Voltage:	12V
Current:	1.0A
Spring Force:	100gf
Coating:	Au 1u”
Temperture:	-40℃~+85℃
Salt Spray:	24 hours
Durability:	20,000 cycles

Part Number:	APC0401-40515
Length:	15.89mm
Working Stroke:	0.50mm
Full Stroke:	0.60mm
Plunger OD:	φ0.45mm, M1.2*0.35
Barrel OD:	φ1.25mm
Tail Pin:	φ1.21mm
Contact Resistance:	1000mΩ
Voltage:	12V
Current:	0.5A
Spring Force:	100gf
Temperature:	-25℃~+85℃
Salt Spray:	24 hours
Durability:	10,000 cycles

Part Number:	APC0401-42020
Length:	18.45mm
Working Stroke:	1.00mm
Full Stroke:	2.95mm
Plunger OD:	φ5.00mm
Barrel OD:	φ5.80mm
Tail Pin:	M3.0*0.5
Contact Resistance:	200mΩ
Voltage:	12V
Current:	2.0A
Spring Force:	115gf
Temperature:	-25℃~+85℃
Durability:	10,000 cycles

Part Number:	APC0401-19497
Length:	18.50mm
Working Stroke:	1.50mm
Full Stroke:	3.20mm
Plunger OD:	φ4.00mm
Barrel OD:	φ5.00mm
Tail Pin:	M3*0.5
Contact Resistance:	100mΩ
Voltage:	12V
Current:	3.0A
Spring Force:	360gf
Coating:	Au 3u”
Temperature:	-40℃~+85℃
Salt Spray:	48 hours
Durability:	100,000 cycles

Part Number:	APC0401-13414
Plunger Tip:	Round
Length:	19.00mm
Working Stroke:	2.10mm
Plunger OD:	φ2.20mm
Barrel OD:	M4.0*0.70
Tail Pin:	3.00mm
Contact Resistance:	30mΩ
Voltage:	24V
Current:	5.0A
Spring Force:	200gf
Coating:	Au 30u”
Temperature:	-40℃~+105℃
Salt Spray:	48 hours
Durability:	50,000 cycles

Part Number:	APC0401-13421
Plunger Tip:	Crown
Length:	19.00mm
Working Stroke:	2.10mm
Plunger OD:	φ2.20mm
Barrel OD:	M4.0*0.70
Tail Pin:	3.00mm
Contact Resistance:	30mΩ
Voltage:	24V
Current:	5.0A
Spring Force:	200gf
Coating:	Au 30u”
Temperature:	-40℃~+105℃
Salt Spray:	48 hours
Durability:	50,000 cycles

Part Number:	APC0401-17362
Length:	19.40mm
Working Stroke:	4.00mm
Full Stroke:	4.00mm
Plunger OD:	φ2.20mm
Barrel OD:	M4.0*0.70
Tail Pin:	3.00mm
Contact Resistance:	30mΩ
Voltage:	24V
Current:	10.0A,peak 12.6A
Spring Force:	200gf
Coating:	Au 30u”
Temperature:	-40℃~+105℃
Salt Spray:	48 hours
Durability:	50,000 cycles

Part Number:	APC0401-26105
Length:	23.00mm
Working Stroke:	5.00mm
Full stroke:	5.20mm
Plunger OD:	φ5.00mm
Barrel OD:	φ5.00mm
Tail Pin:	M6.00
Spring Force:	650gf
Coating:	SUS 304
Temperature:	-25℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-13820
Length:	24.70mm
Working Stroke:	5.50mm
Full Stroke:	6.00mm
Plunger OD:	φ4.00mm
Barrel OD:	M8.0*1.25
Tail Pin:	φ5.00mm
Contact Resistance:	50mΩ
Voltage:	12V
Current:	1.0A
Spring Force:	1800gf
Coating:	Au 10u”
Temperature:	-40℃~+85℃
Salt Spray:	96 hours
Durability:	100,000 cycles

Part Number:	APC0401-32944
Length:	24.77mm
Working Stroke:	2.00mm
Full Stroke:	2.40mm
Plunger OD:	φ3.30mm
Barrel OD:	φ6.35mm
Tail Pin:	6-32 UNC-2A
Contact Resistance:	30mΩ
Voltage:	30V
Current:	5.0A
Spring Force:	225gf
Coating:	Au 10u”
Temperature:	-35℃~+105℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-48031
Length:	27.50mm
Working Stroke:	1.00mm
Full Stroke:	4.00mm
Plunger OD:	φ6.00mm
Barrel OD:	φ9.00mm
Tail Pin:	φM5.0,9.50mm
Contact Resistance:	100mΩ
Voltage:	12V
Current:	50.0A
Spring Force:	540gf
Coating:	Au 10u”
Temperature:	-40℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-40579
Length:	28.70mm
Working Stroke:	1.67mm
Full Stroke:	2.00mm
Plunger OD:	φ0.50mm
Barrel OD:	φ6.00mm
Tail Pin:	1/4-36UNS-2A
Contact Resistance:	100mΩ
Current:	1.0A
Spring Force:	0.637N
Coating:	Au plated
Temperature:	-40℃~+80℃
Durability:	100,000 cycles

Part Number:	APC0401-10471
Length:	33.50mm
Working Stroke:	10.00mm
Full Stroke:	10.00mm
Plunger OD:	M3.00,φ4.00mm
Barrel OD:	φ5.00mm
Spring Force:	10N
Temperature:	-25℃~+85℃
Salt Spray:	48 hours
Durability:	100,000 cycles

Part Number:	APC0401-19322
Plunger tip:	Round
Length:	35.00mm
Working Stroke:	10.00mm
Plunger OD:	φ5.00mm
Barrel OD:	φ6.00mm
Tail Pin:	M3.0*0.5
Contact Resistance:	100mΩ
Voltage:	24V
Current:	0.5A
Spring Force:	100gf
Coating:	Au 5u”
Temperature:	-25℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-19323
Plunger tip:	Ball
Length:	35.00mm
Working Stroke:	10.00mm
Plunger OD:	φ5.00mm
Barrel OD:	φ6.00mm
Tail Pin:	M3.0*0.5
Contact Resistance:	100mΩ
Voltage:	24V
Current:	0.5A
Spring Force:	100gf
Coating:	Au 5u”
Temperature:	-25℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-37739
Length:	42.00mm
Working Stroke:	10.00mm
Full Stroke:	11.00mm
Plunger OD:	φ4.00mm, M6*1.0
Barrel OD:	φ8.00mm
Tail Pin:	φ6.00mm
Contact Resistance:	50mΩ
Voltage:	12V
Current:	2.0A
Spring Force:	100gf
Coating:	Au 5u”
Temperature:	-30℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-42021
Length:	49.00mm
Working Stroke:	5.00mm
Full Stroke:	7.00mm
Plunger OD:	φ5.00mm
Barrel OD:	φ6.00mm
Tail Pin:	M4*0.7
Contact Resistance:	50mΩ
Voltage:	12V
Current:	10.0A
Spring Force:	500gf
Coating:	Au 3u”
Temperature:	-25℃~+85℃
Salt Spray:	48 hours
Durability:	10,000 cycles

Part Number:	APC0401-33126
Length:	58.50mm
Working Stroke:	10.00mm
Full Stroke:	15.00mm
Plunger OD:	M2.5
Barrel OD:	φ5.00mm
Tail Pin:	φ8.00mm
Spring Force:	350gf
Coating:	NI 80~150u”
Temperature:	-25℃~+85℃
Salt Spray:	48 hours
Durability:	100,000 cycles

Part Number:	APC0401-28548
Length:	70.00mm
Working Stroke:	15.00mm
Full Stroke:	18.00mm
Plunger OD:	φ17.00mm
Barrel OD:	φ15.80mm
Tail Pin:	M12.00
Contact Resistance:	20mΩ
Voltage:	24V
Current:	120A
Spring Force:	3000gf
Coating:	Ag plated
